| APPLY LEVER, Front |
| 47561 parts in stock comprising 18337 unique part numbers from 56101 numbers listed. (12/05/2025) |
| Style |
Color
Code |
OA/Thick |
OD/Deep |
ID/Wide |
Our Part Number |
Price |
Picture |
| Tooth Counts |
ID Marks |
| Year |
Miscellaneous Info |
|
| Years |
|
Part Info |
Number |
|
| Call 877-771-3372 for current price & availability ( 8am - 8pm Pacific Time ) |
|
A
|
BYO.L
|
1-63/64"
|
|
32/64"
|
FD-C6F-8F-0004-HE
|
Price
|
Enlarge
|
| |
A, C6AP-7D396-A
|
|
74-83
|
Ratio = 1.65
Fits between front servo pin and front band apply strut
Multiplies the application force against the front band
|
|
| |
|
LEVER, Intermediate Servo Band
|
D4AZ-7330-A
|
|
|
B
|
LVV.N
|
|
|
|
FD-C6F-8F-0005-KG
|
Price
|
Enlarge
|
| |
B
|
|
66-82
|
Ratio = 1.73
Fits between front servo pin and front band apply strut
Multiplies the application force against the front band
|
|
| |
|
LEVER, Intermediate Servo Band
|
C6AZ-7330-B
|
|
|
C
|
REE.R
|
|
|
|
FD-C6F-8F-0008-5N
|
Price
|
Enlarge
|
| |
C
|
|
66-80
|
Ratio = ????
Fits between front servo pin and front band apply strut
Multiplies the application force against the front band
|
|
| |
|
LEVER, Intermediate Servo Band
|
C6AZ-7330-C
|
|
|
D
|
BKY.K
|
|
|
|
FD-C6F-8F-0002-N8
|
Price
|
Enlarge
|
| |
D
|
|
66-89
|
Ratio = 1.97
Fits between front servo pin and front band apply strut
Multiplies the application force against the front band
|
|
| |
|
LEVER, Intermediate Servo Band
|
C6VY-7330-A
|
|
|
E
|
Y:BRK
|
1-62/64"
|
|
32/64"
|
FD-C6F-8F-0000-J4
|
Price
|
Enlarge
|
| |
E, C6AP-7D396-C
|
|
66-82
|
Ratio = 1.85
Fits between front servo pin and front band apply strut
Multiplies the application force against the front band
|
|
| |
|
LEVER, Intermediate Servo Band
|
C6AZ-7330-D
|
|
|
F
|
GBG
|
|
|
|
FD-C6F-8F-0001-L6
|
Price
|
Enlarge
|
| |
F
|
|
66-80
|
Ratio = 2.30
Fits between front servo pin and front band apply strut
Multiplies the application force against the front band
|
|
| |
|
LEVER, Intermediate Servo Band
|
C6AZ-7330-E
|
|
|
H
|
V:YRB
|
|
|
|
FD-C6F-8F-0003-FA
|
Price
|
Enlarge
|
| |
H, C8VP-7D396-B
|
|
68-80
|
Ratio = 2.18
Fits between front servo pin and front band apply strut
Multiplies the application force against the front band
|
|
| |
|
LEVER, Intermediate Servo Band
|
C8VY-7330-B
|
|
|
J
|
BYG.E
|
1-63/64"
|
|
32/64"
|
FD-C6F-8F-0009-7Q
|
Price
|
Enlarge
|
| |
J
|
|
|
Ratio = 1.495
Fits between front servo pin and front band apply strut
Multiplies the application force against the front band
|
|
| |
|
LEVER, Intermediate Servo Band
|
E0TZ-7330-A
|
|
|
K
|
VGG.O
|
1-63/64"
|
|
32/64"
|
FD-C6F-8F-000A-G8
|
Price
|
Enlarge
|
| |
K
|
|
80-96
|
Ratio = 1.575
Fits between front servo pin and front band apply strut.
Multiplies the application force against the front band.
|
|
| |
|
LEVER, Intermediate Servo Band
|
E0TZ-7330-B
|
|
