  Page number:  GM-640-990
ADAPTER HOUSING, 4x4
47060 parts in stock comprising 18111 different part numbers out of 55605 listed. (08/28/2025)
Style Color
Code		 OA/Thick OD/Deep ID/Wide Our Part Number Price Picture
Tooth Counts ID Marks
Year Miscellaneous Info
Years   Part Info Number
Call 877-771-3372 for current price & availability ( 8am - 8pm Pacific Time )
Chevy

Squat

Aluminum 		YRG 2-7/16"     GM-640-99-000F-8R Price Picture
not
available
  12339134
  Aluminum
6x6 bolts
Mount = Offset, 5-1/2" bolt span, 1/2" NC threads
2-7/16" face to face
Squat
Known to fit 7" output shaft
Known to fit TH400, Aluminum transfer cases
Chevy

Squat

Iron

2-1/2" long 		GVR 2-1/2"     GM-640-99-0009-LW Price
Enlarge
  15597795
85-90 Cast iron
6x6 bolts
Mount = Offset, 7-1/2" bolt span, 10mm threads
2-1/2" face to face
Squat
    ADAPTER, Transfer Case 15597795
Chevy

Squat

Iron

4" long 		GEY 4"     GM-640-99-001M-G8 Price Picture
not
available
  15597799
85-90 Cast iron
6x6 bolts
Mount = Bottom, Offset, 7-1/2" bolt span, 10mm threads, 3-5/8" center to bottom of foot
4" face to face
Known to fit " output shaft
Known to fit NP205C, TH400
    ADAPTER, Transfer Case 15597799
Chevy

Tall

NP 203C 		LOY 1-1/8"     GM-640-99-0038-MX Price Picture
not
available
  376129
  Cast iron
6x7 bolts
1-1/8" face to face
Tall
Known to fit NP 203C, TH400
Chevy

Tall

NP 205C 		YOG       GM-640-99-001N-7A Price Picture
not
available
  13930
  Cast iron
6x8 bolts
Mount = Bottom, 7-1/2" bolt span, threads, " center to bottom of foot
" face to face
Known to fit " output shaft
Known to fit NP205C, TH400
    ADAPTER, Transfer Case 14022218
Chevy

Tall

NP 208C 		VVG 2-1/2"     GM-640-99-0037-KV Price
Enlarge
  14020861
  Cast iron
6x6 bolts
Mount = Bottom, Tall, 6" bolt span, 1/2" threads
2-1/2" face to face
Known to fit NP 208C, TH400
Jeep

Dana 20 		LGE 2-1/2"     GM-640-99-001T-AQ Price
Enlarge
  8624113
  Jeep
Aluminum
6x5 bolts
Mount = Bottom
Jeep

Quadratrack 		YRE 2-5/8"     GM-640-99-0039-E0 Price
Enlarge
  8627466
74-79 Jeep
Aluminum
6x4 bolts
Known to fit Quadratrack, TH400
    EXTENSION HOUSING 8627466
  Last updated:  08/28/2025
